Datamax-O'Neil M Class Mk II
The M-Class Mark II is a compact industrial strength printer series that offers the power and performance required in industrial environments, the reliability demanded in commercial applications and a small footprint when space is a consideration. It combines powerful standard features with a variety of flexible options to meet the broadest possible range of applications.
The solid die-cast metal construction, large graphical display and modular design set the M-Class printer family a step above its competitors. The printer's solid cast metal chassis and durable steel cabinet offer rugged and reliable performance. The easy-to-use graphical display makes navigation through the menus quick and simple for any level user. The modular design offers the flexibility to quickly replace parts in the field or install options to meet changing business requirements.
M Class Mk II Quick Facts
Resolutions : 203 & 300dpi
Processors :
M-4206 - 100 MHz Dragonball
M-4210 & M4308 - 150 MHz Dragonball
Print Method : Direct Thermal or Thermal Transfer
Print Speeds : Up to 250mm/sec (Model dependant)
Media Width : 19 -> 118mm (0.75' -> 4.65')
Label Length : 6mm -> 2.4M
Std. Memory : 16Mb DRAM / 8Mb FLASH
Std. PC Interface : Serial, Parallel and USB
Options
Peel & Present
Internal Re-Wind
4Mb Flash Memory Upgrade (M-4206)
64Mb Flash Memory Upgrade (M-4210 & M-4308)
MCL Enabled (M-4210 & M-4308 only)
RFID Capable - UHF & HF (M4210 & M-4308)
Internal 10/100 Ethernet
Internal 802.11b/g Wireless Ethernet
USB Host Interface
Hangul, Kanji & Simplified Chinese support
Documents & Downloads (Click on ICON to Download File)
M Class Mk II Data Sheet
M Class Mk II Quick Start Guide (500 kb)
M Class Mk II Users Manual (2 MB)
M Class Mk II Ethernet II Guide (1.9 MB)
Class Series Programmers Manual - v11+ Firmware (3 Mb)
The latest Windows Drivers and Printer configuration utility
Chapter 3 - Printer Operation
23
3.4.3 Standard Calibration
The Standard Calibration can be performed using the NETira CT Utility (see Section 3.3)or using
the front panel buttons via the printer’s menu, see Section 4.5. Standard Calibration provides
dynamic readings, which can be helpful when using media with small position-critical notches or
marks. Three calibration samples are required:
Empty – with nothing over the sensor;
Gap, Notch, Hole or Mark – with media liner, a notch, hole, or a mark over the sensor; and,
Paper – with the label (and liner, if any) over the sensor.
Calibrate the Media Sensor using the steps below:
The Sensor Calibration menu item is only accessible in the Advanced Menu mode.
Step
Action
Displayed Message
Comment
A
Turn ON the printer.
READY
Wait briefly for initialization to
complete.
B
Press MENU Button. Make sure
MEDIA SETTINGS is highlighted
and press ENTER.
Then using the DOWN Button,
scroll to SENSOR CALIBRATION.
(Printer Menu)
C
Press ENTER to access SENSOR
CALIBRATION. Then using the
DOWN Button, scroll to PERFORM
CALIBRATION. Press ENTER again
and then press YES to proceed.
PERFORM CALIBRATION
Press NO to abort this procedure.
D
With no media installed, press
ESC.
REMOVE LABEL STOCK
PRESS ESC KEY
Yyy
This sets the empty value, where
“yyy” represents the current
sensor reading.
E
Proceed according to the media
type:
Die-Cut – Remove a label or two
from the liner then install the
media. Position the Media Sensor
under the liner area and press
ESC.
Notched (or Reflective) – Install
media. Position the Media Sensor
under a notch (or black mark) and
press ESC.
Continuous – Press ESC then
proceed to Step F.
